Cisco Aironet AIR-AP1832I-B-K9 Wireless Access Point, 802.11ac Wave 2, Internal Antennas (Refurbished)

Cisco Aironet AIR-AP1832I-B-K9 Dual-Band Wireless Access Point

The Cisco AIR-AP1832I-B-K9 is an indoor enterprise wireless access point from the Aironet 1830 Series. It provides dual-band 802.11ac Wave 2 connectivity, integrated internal antennas and MU-MIMO capability for business WLAN deployments.

Wireless specifications

• Manufacturer part number: AIR-AP1832I-B-K9
• Product family: Cisco Aironet 1830 Series (1832i)
• Wi-Fi standards: IEEE 802.11a/b/g/n/ac Wave 2
• Radio bands: 2.4 GHz and 5 GHz concurrent operation
• MIMO: 3x3 radio design with two spatial streams
• Maximum 5 GHz PHY rate: Up to 867 Mbps
• Antennas: Integrated internal antennas
• Wireless features: MU-MIMO, transmit beamforming and Cisco Radio Resource Management

Interfaces and physical details

• One 10/100/1000BASE-T Gigabit Ethernet uplink with PoE
• RJ-45 console/management interface
• USB 2.0 interface (availability depends on software configuration)
• Ceiling or wall mounting using a compatible bracket
• Dimensions (without bracket): approximately 210.8 x 210.8 x 50.8 mm
• Weight: approximately 930 g

Deployment and compatibility

This is the B regulatory-domain model. Check local regulatory approval, supported channel set and controller software compatibility for the country and network design. The AIR-AP1832I-B-K9 is the standard controller-based K9 ordering variant. The configurable K9C variant is the one factory-shipped with Cisco Mobility Express software; do not assume Mobility Express primary-AP capability for this K9 SKU.

Model distinction: The suffix I identifies the internal-antenna version; do not confuse it with the external-antenna 1832E. The B-domain PID is different from the E-domain AIR-AP1832I-E-K9.

Condition: Used. Confirm exact PID label, mounting bracket and power accessories supplied with the unit.
