90W Lenovo Laptop Charger PA-1900-52LC / ADP-90RH B, 19V 4.74A, 5.5mm x 2.5mm

90W Lenovo-compatible laptop AC adapter for systems requiring 19V DC, 4.74A and a 5.5mm x 2.5mm barrel connector.

Power

Wattage: 90W

Voltage: 19V DC

Current: 4.74A

Input: 100–240V AC, 50/60Hz

Connector: 5.5mm x 2.5mm

Compatible Part Numbers

PA-1900-52LC, ADP-90RH B, 0713A1990, 0225A2040, 02K6900, 0712A1965, 11J8627, 40Y7700, 40Y7704, 40Y7708, 40Y7710, 41R4322, 41R4326, 41R4327, 41R4332, 41R4336, 41R4338, 41R4515, 41R4516, 41R4519, 41R4520, 41R4521, 41R4523, 41R4524, 41R4525, 41R4526, 42T4457, 42T4458, 42T4459, 42T4465 and 45J7717. These codes appear on multiple replacement-adapter listings for the same 19V/4.74A connector specification; verify the exact original label before ordering.

Important Part-Number Note

40Y7696 has been removed from the compatibility list. Lenovo's support documentation identifies 40Y7696 as a ThinkPad 65W ultraportable AC adapter marketing part number, so it conflicts with this listing's 90W, 19V/4.74A specification.

Compatible Laptop Models

Online replacement listings associate this 90W adapter family with various Lenovo IdeaPad and IBM/ThinkPad models, but the exact models for this physical unit have not been independently confirmed. Check the laptop's required voltage/current and original adapter part number before ordering.

Before Ordering

Use only when the laptop requires 19V, up to 4.74A, 90W and the same 5.5mm x 2.5mm connector. Do not select by brand or part number alone.
